Technical Specifications
AC current (A) 40A/400A ±(2.5%+5)
AC current frequency (Hz) 50Hz~100Hz
DC current (A) 40A/400A ±(2.5%+5)
AC voltage (V) 600V ±(0.8%+5)
AC voltage frequency(Hz) 10Hz~60kHz ±(0.5%+2)
DC voltage (A) 600V ±(0.5%+2)
Resistance (Ω) 40MΩ ±(0.8%+2)
Capacitance (F) 40mF ±(4%+5)
Frequency (Hz) 10Hz~10MHz ±(0.1%+4)
Display count 4000
Auto range √
Jaw opening 28mm
True RMS √
NCV √
Continuity test √
Diode √
MAX/MIN √
Relative mode √
Zero mode √
Data hold √
Low battery indication √
Auto power off √
General Characterisitics
Power 1.5V battery (R03) x 2
Display 37mm x 25mm
Product color Red and grey
Product net weight 235g
Product size 215mm x 63mm x 36mm
Standard individual packing Gift box, Carring bag, English manual
Warranty:
1 Year- Brand
