Technical Specifications
Model - DIN-63
Dimensions - 76x27x116
Panel Cutout Din Rail Mounting
Range: 999, 99.9, 9.99 Hour/Min/ Sec (Configurable)
Output: 1 Relay, 2C/O, 5A, 230V AC, 12V DC SSR Output (Any one Factory Set)
Operation Mode: Delayed ON/OFF (Configurable)
Counting Direction: UP/Down(Configurable)
Memory: Yes/No (Configurable)
Supply: 100-250 AC 50/60Hz
Warranty:
1 Year- Brand Warranty
Uses
A timer is a specialized type of clock used for measuring specific time intervals. Timers can be categorized into two main types. A timer which counts upwards from zero for measuring elapsed time is often called a stopwatch, while a device which counts down from a specified time interval is more usually called a timer.
