Technical Specifications
- Model: UTR 1044
- Dimensions: 96x96x50
- Panel Cutout: 92x92
- Sensor: Micro/Limit/ Proximity (Connfigurable)
- Range: 99.99/999.9/999 Sec/Min/Hrs (Configurable)
- Output: 1 Relay, 2C/O, 5A, 230 AC, 12V DC SSR Output (Any One Factory Set)
- Operation Mode: Delayed ON/OFF/Cycle Mode (Configurable)
- Count Direction: Up/Down (Configurable)
- Memory: Yes/ No (Configurable)
- Reset: Front and back
- Supply: 100-250AC, 50/60Hz
Warranty:
1 Year- Brand Warranty
Uses
The Programmable Timer is used for measurement, display and control in applications that have variables. A Programmable Timer can also work with a single input or, in some cases, a pair of signals. Timers exist because many processes are based upon timed events.
