Technical Specifications
- Model: UTC- 1202
- Dimensions: 96x96x50
- Panel Cutout: 92x92
- Sensor: J/K/PT-100 2W/3W (Configurable)
- Range: J (0-600 C), K(0-1200 C), PT 100 2W/3W (-99 to 400, -99.9 to 400 C)
- Output: 2 Relay 1C/O, 5A, 230V AV & SSR 12V DC Parallel (2 Set Point)
- Operating Mode: High/Low/Inband/Outband/ Absolute Low/ Absolute Outband Alarm - (Configurable) + Soak Timer
- Control Action: PID ON- OFF (Configurable)
- Accuracy: 1% of FSD
- Supply: 100-250 AC, 50/60 Hz
Warranty:
1 Year- Brand Warranty
Uses
A controller in a temperature control system will accept a temperature sensor such as a thermocouple or RTD as input and compare the actual temperature to the desired control temperature, or setpoint. It will then provide an output to a control element.
