Technical Specifications
- Display: LCD,1999 counts, updates 2-3 or sec
- DC Voltage 2V/20V/200V, 1000V +-(1.0%+2)
- AC Voltage 200V/750V
- AC Current 200A, 2000A(<600A), 2000A(600A~1000A), 2000A(>1000A)
- Resistance 200Ω, 20KΩ/2MΩ
- Frequency: 2kH, 20kHz
- Temperature: 0℃~400℃(32℉~752℉), 401℃~750℃(753℉~1382℉)
Warranty:
As per Mastech's policy- 1 Year
Uses
Clamps measure current. Probes measure voltage. Having a hinged “clamp” jaw integrated into an electrical meter allows users to simply clamp around wire, cables and other conductors at any point in the electrical system and measure its current, without disconnecting it.
