Technical Specifications
- Voltage:
12V min 8V±1V
24V min 18V±2V
50V min 38V±4V
120V min 94V±8V
230V min 180V±14V
400V min 325V±15V
690V min 562V±24V
- Phase rotation test 100V~690V, 50Hz~60Hz
- Single pole test100V~690V, 50Hz~60Hz
- RCD test
- Self-test
- No Power test 100V~690V
- voltage indication - LEDs
- IP65 Rated
- Autorange
- low battery indication
- exceed voltage 713V~788V
- silent mode
- LCD display (Voltage) 6V-690V ±(1.5%+5)
- LCD display (Frequency) 40Hz-400Hz ±(3%+5)
- Power 2x1,5V battery R03
- LCD size: 31x20mm
- Weight 280g
- Size 272x85x31mm
- Accessory: battery, manual
Warranty:
As per UNI-T warranty policy
Uses
A test light, test lamp, voltage tester, or mains tester is a piece of electronic test equipment used to determine the presence of electricity in a piece of equipment
