Technical Specifications
- DC Voltage (V) 400mV/4V/40V/400V/1000V ±(0.8%+1)
- AC Voltage(V) 4V/40V/400V/750V ±(1%+5)
- DC Current (A) 400mA/4000mA/40mA/400mA/10A ±(1%+2)
- AC Current (A) 400mA/4000mA/40mA/400mA/10A ±(1.5%+5)
- Resistance (Ω) 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ ±(1%+2)
- Capacitance (F) 4nF/40nF/400nF/4μF/40μF/400μF/4μF/40μF ±(4%+3)
- Frequency 4kHz/40kHz/400kHz/4MHz/40MHz/400MHz ±(0.1%+3)
- Temperature(°C) -40℃～1000℃ ±(1%+3)
- Temperature(°F) -40℉～1832℉ ±(1%+4)
- RPM 40kRPM ±(0.1%+3)
- Input Impedance for DC Voltage Measurement 10MΩ √
- Power 9V Battery (6F22)
- LCD Size 62mm×53mm
- Product Net Weight 600g (including holster)
- Product Size 195mm×90mm×40mm
Warranty:
As per UNI-T warranty policy
