UNI-T
UT89X Digital Multimeter
UT89X is a reliable hand-held 3 5/6 bit digital multimeter with true RMS sine wave measurement. It can measure Max. 1000V DC/AC voltage, Max. 20A DC/AC current, resistance, capacitance, frequency, diode, hFE, continuity and NCV, quickly distinguishing between neutral and live wires accurately. UT89X can measure temperature and detect neutral and live wires with a test lead. It attracts users with its bi-color durable case, modern exterior and multiple functions.
- 1000V AC/DC； 20A AC/DC
- True RMS, 6000 count
- Dual range NCV test which quickly identifies neutral and live wires through light intensity
- Audible/visual alarm
- Capacitor charging indicator
- Ergonomic design
- Double injection molding
- 1m drop proof
- Flashlight; Auto backlight
Rs.
3,000.00 Save Rs. 850
(29% Off)
Rs.
2,150.00
/each (Incl
GST-18%)
4 in Stock
Technical Specifications
- DC voltage (V) 600mV/6V/60V/600V/1000V ±(0.5%+2)
- AC voltage (V) 6V/60V/600V/1000V ±(0.8%+5)
- DC current (A) 60μA/60mA/600mA/20A ±(0.8%+8)
- AC current (A) 60mA/600mA/20A ±(1%+12)
- Resistance (Ω) 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ ±(0.8%+3)
- Capacitance (F) 6nF/60nF/600nF/6μF/60μF/600μF/6mF/60mF/100mF ±(2.5%+20)
- Frequency (Hz) 9.999Hz/9.999MHz ±(0.1%+4)
- Duty cycle 0.1%~99.9% ±(2%+5)
- Temperature (℃) -40℃~1000℃ ±(2%+4)
- Temperature (℉) -40℉~1832℉ ±(2%+8)
- Display count 6000
- Sampling rate 3 times/s
- True RMS √
- AC voltage frequency response 45~1000Hz
- AC current frequency response 45~1000Hz
- Live wire test √
- Audible/visual alarm V/A/Cap/Diode/hFE/NCV/Live
- Diode/Continuity test √
- Transistor hFE √
- Dual range NCV test √
- Auto power off √
- Low battery indication √
- Data hold √
- Function selection SELECT √
- Flashlight √
- Auto backlight √
- Power 1.5V battery (R03) x 4
- Display 61mm x 36mm
- Product color Red and grey
- Product net weight 345g
- Product size 189mm x 89mm x 53mm
- Standard accessories Batteries, test lead, k-type temperature probe
Warranty:
1 Year
Uses
Feature packed professional use multimeter
